RELIABLY FUNCTIONAL, INFINITELY ADAPTABLE SYSTEMS.

The key feature of this system is the patented sliding clip on infill panels. The benefit is the ability for exclusive downward access to the plenum.

PRODUCT DETAILS

Dimensions:

• Blade width: 3/8″
• Blade Height: 2″
• Modules: Variety of options in Square, Rectangular, or Patterned

Key Features

• Patented sliding clip on factory-assembled panels allow install in matching runners
• No T-grid for monolithic appearance
• Waste reduction with factory fabricated dimensional material
• Downweight: reduce dead load with lightweight aluminum
• Easy plenum access – downward accessible panels
• Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
• High recycled aluminum content
• No VOCs: No added urea-formaldehyde
• GREENGUARD Gold Certified

Physical Data

• Substrate: Aluminum
• Warranty: 1 year
• Seismic rating: Zones A, B, C, D, E, F
• Fire rating: Class A Fire Rated per ASTM E84
• Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
• Weight: Varies 0.5 – 1.25 lbs/sq. ft.
• Wind load: N/A
• Recycled content: Up to 92%
• Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
• Cotton White: LR = 0.81
