A CLASSIC LOOK WITH THE DURABILITY TO MATCH.

The key feature of this system is the variable carrier system and custom perforation options. The benefit is design flexibility without sacrificing proficiency or accessibility.

PRODUCT DETAILS

Two panel size sets:

• 6″ to 24″ widths up to 120″ long
• 30″ width up to 60″ long

Key Features

• Square-edge design
• Waste reduction with factory fabricated dimensional material
• Downweight: reduce dead load with lightweight aluminum
• Easy plenum access
• Compatible with industry standard lighting, HVAC, speaker, fire safety and security services
• High recycled aluminum content
• No VOCs: No added urea-formaldehyde
• GREENGUARD Gold Certified

Physical Data

• Substrate: Aluminum
• Warranty: 1 year
• Seismic rating: Zones A, B, C, D, E, F
• Fire rating: Class A Fire Rated per ASTM E84
• Painted or anodized metal: Flame spread: ≤ 25, Smoke ≤ 50
• Weight: Varies 1.0 – 1.5 lbs/sq. ft.
• Wind load: Per code (for exterior applications)
• Recycled content: Up to 85%
• Light reflectance (LR) Coefficient per ASTM E1264 & ASTM E1477:
• Cotton White: LR = 0.81
